3 Directional Blowing Automatic Induction Class 100 Air Shower For Cleanroom Project

Brand Name : KELING

Model Number : KEL-AS1500P3

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 30 sets per month

Delivery Time : 8-15 working days

Packaging Details : Polywood Packing

Name : Auto Air Shower

Material : Stainless Steel, Cold-rolled

Air speed : >25m/s

Features : 3 Directional Blowing

Capacity : 1-6 person

Packing : Polywood Packing

Contact Now

3 Directional Blowing Automatic Induction Class 100 Air Shower for Cleanroom Project

Cleanroom Air Showers
Air showers are a vital component in maintaining the cleanliness of cleanrooms and other clean-critical environments.
Using high-velocity jets of air, air showers remove loose particles of contamination from people and products before they enter a cleanroom,
reducing or eliminating product defects for increased yields.

Additionally, air showers reduce the need for cleanroom maintenance because the contamination load will be lower.
Your cleanroom’s HEPA filters will last longer, and overall energy costs will be reduced.

Clean Air Products offers high performance standard and custom cleanroom air showers.
Request a quote or contact us for the air shower you need.
karen@haoairtech.com

Products Specification:

MODEL KEL-AS1400V1 KEL-AS1400V2 KEL-AS1400V3

External size (mm)

(WXDXH)

 1400x1000x2180 1400x2000x2180 1400x3000x2180

Work zone (mm)

(WXDXH)

 790x930x1910 790x1930x1910 790x2930x1910
Persons per cycle 1-2 person 2-4 person 3-6 person

Material

(Option)

1:Entirety Sus304.(T=1.0/1.2/1.5mm)

2:Entirety sus201. (T=1.0/1.2/1.5mm)

3: External is steel with power coated, Internal is SUS304

4: External is steel with power coated. Internal is SUS201
Control system

1: Control system with LED display for the shower time.

2: The shower time from 0-99second. (Adjustable)

3: Infrared ray inductor for inside personal shower automatic.

4: Vertical top side blowing with Human voice prompt system.

5: with CE remark.
The power of fan

380V/50HZ/1.1KW

(1 set)

380V/50HZ/1.1KW

(2 sets)

380V/50HZ/1.1KW

(1sets)
Air flow of fan(m3/h) 1500 1500 1500
Fan run (r/min) 2800 2800 2800
Nozzle in stain less steel 16 pcs 32 pcs 48pcs
Wind speed(m/s) >25m/s
Noise level(dB) <75dB
HEPA FILTER Size(mm) 630X630X80mm 630X630X80mm 630X630X80mm
Efficiency (%) 99.995% @ 0.3um Mini-pleats HEPA air filter
Air velocity 1000m3/h
Initial resistance(pa) <220pa
Pre-filter Size(mm) 775x380x17 775x380x17 775x380x17
Efficiency(%) 75% @ 0.5um 75% @ 0.5um 75% @ 0.5um
G3 G3 G3
resistance(pa) <30 Pa <30Pa <30 Pa
parameter Power supply 380v/50Hz 380v/50Hz 380v/50Hz
Net power(kw) 1.5 kw 3kw 4.5 kw
packing size (mm) 1500x1200x2250 1500x2200x2250 1500x3200x2250
Packing material Standard Export Poly wood Packing(Fumigant free material)
Weigh 320kgs 650kgs 960kgs

Our Services
Factory testing (all the sets you ordered):
All of equipment is individually factory tested for safety and performance in accordance with international Standards.
Each unit is shipped with a documentation outlining the tests undertaken and the unit’s individual results for each unit.
Factory test include:
--appearance testing
--functional test and visual inspection
--electrical safety tests
--air velocity testing
--noise testing

Warranty:
Our equipment is warranty for 2 years excluding consumable parts and accessories.
All equipment is shipped with a comprehensive use’s manual complete with a report documenting all test procedures.
Additional IO/OQ/GMP document is available upon request.

Contact our sales representative for specific warranty details or document request.
